30Kw PE400*600 Mobile Cone Crusher , Primary Stone Crusher 36 24

Name: 30Kw PE400600 Mobile Cone Crusher Primary Stone Crusher 36 24
Brand: RUNWELL
Price: 10000 USD

30Kw PE400*600 Mobile Cone Crusher , Primary Stone Crusher 36 24 Manufactures

Brand Name : RUNWELL

Model Number : PE400*600 Small jaw crusher

Certification : CE,ISO certificates

Place of Origin : Shanghai, China

MOQ : 1 set

Price : USD 10000-15000

Payment Terms : T/T, Western Union, L/C, MoneyGram

Supply Ability : 100 sets per month

Delivery Time : 10-20 working days

Packaging Details : Container, Nude Packs, in Bulk; Export Packing Standard

Motor Type : AC motor,380V,50Hz

Feeding sizes : 350mm

Capacity(t/h) : 16-60tph

Discharge Range : 40-100mm

Power(Kw) : 30Kw

Color : Gray, White, Yellow, Customer-Specified

Warranty : 12 months from production time or 15 months from leave factory

Transport Package : Container, in Bulk; Export Packing Standard

After-sales Service : Engineer Assigned

Type : PE series Jaw Crusher

Application : Mining,Quarry,Construction,Stone

After-sales service provided : Engineers available to service machinery overseas,Video technical support

Spare parts supply : All the using time

The machines classification : Building Stone Production Line,Quarry

Installation : Under Engineer's Guide

Name : Jaw Crusher,Stone jaw crusher in indonesia /in Philippines jaw crusher machine price for sale

Contact Now

**Jaw Crusher for Primary Stone Crushing Stage as Mining Crusher for Mining Project PE400*600**

Product Description

Jaw Crusher is ideally suitable for primary and secondary crusher for material with compression strength less than 320MPA. Jaw Crusher is of high crushing ratio, larger capacity, well-distributed final product size, simple structure, reliable performance, convenient maintenance, lower operation cost, etc. It is widely used in mining, metallurgy, construction, highway, railroad, and water conservancy, etc.

30Kw PE400*600 Mobile Cone Crusher , Primary Stone Crusher 36 24

Working Principle

The electrical motor transmits power to the eccentric shaft through v-belt and belt pulley.

Then the exciting force generated by the eccentric shaft will make the movable jaw move upwards and downwards. This movement would trigger the toggle plate to push the movable jaw forwards and backwards. When the movable jaw moves forth towards the fixed jaw, materials in the crushing cavity will be squashed or chopped. And then the movable jaw travels back, the chopped or squashed materials which meet the requirement will be discharged from the outlet. Since the motor keeps working. The crusher will crush and discharge periodically to achieve mass production.

30Kw PE400*600 Mobile Cone Crusher , Primary Stone Crusher 36 24

Features

1. Simple structure, convenient in use and maintenance. Stable performance, low operation cost.

2. The providential cavity design

3. The most classic design,the best manufacturing technique and materials,durable operation.

4. Energy saving: stand-alone energy saving 15% ~ 30%, the system energy saving more than double.

5. The adjustment of discharge opening is convenient and flexible.

6. A variety of jaw plates are optional.

7. The most durable bearings.

8. High-quality cast steel movable jaw head assembly.

30Kw PE400*600 Mobile Cone Crusher , Primary Stone Crusher 36 24

Specification

Model	Feeding size(mm)	Max feeding size(mm)	Discharging Range size(mm)	Capacity (t/h)	Motor power(kw)	Weight (t)
PE-250*400	250*400	210	20-60	5-20	15	2.8
PE-400*600	400*600	340	40-100	16-60	30	6.5
PE-500*750	500*750	425	50-100	40-110	55	10.6
PE-600*900	600*900	500	65-180	80-180	55-75	15.5
PE-750*1060	750*1060	630	80-180	110-320	90-110	28
PE-800*1060	800*1060	680	100-200	140-340	90-110	30
PE-870*1060	870*1060	750	170-270	180-360	90-110	30.5
PE-900*1060	900*1060	780	200-290	200-380	90-110	31
PE-900*1200	900*1200	780	95-225	220-450	110-132	49
PE-1000*1200	1000*1200	850	195-280	280-550	110-132	51
PE-1200*1500	1200*1500	1020	150-300	400-800	160	100.9
PEX-150*750	150*750	120	18-48	8-25	15	3.5
PEX-250*750	250*750	210	25-60	13-35	22	4.9
PEX-250*1000	250*1000	210	25-60	16-52	30-37	6.5
PEX-250*1200	250*1200	210	25-60	20-61	37	7.7
PEX-300*1300	300*1300	250	20-90	25-95	75	11

30Kw PE400*600 Mobile Cone Crusher , Primary Stone Crusher 36 24

Questions & Answers
1. How long is the delivery time of your product?
The delivery time is within 20 working days.

2. What is the payment term?
The payment term is T/T.

3.How long is the product warranty period?
Our warranty period is 1 year, excluding wearing parts.

4.What's the after sale service of your company?
We will provide foundation drawing to the clients for installation. Besides, we can provide guidance service for installation and operation of workers, etc.

5. Can your company provide wearing parts?
We can deliver you the spare parts within 10 working days after your order. If your equipment are not manufactured by our company, please provide us the wearing parts drawing or number.
