580mm Vibrating Hopper Feeder Machine ZSW1149 Model Large Capacity, Vibrating Screen Feeder

  • 1
  • 2
  • 3

Brand Name : RUNWELL

Model Number : ZSW1149

Certification : CE,ISO certificates

Place of Origin : Shanghai, China

MOQ : 1 set

Price : USD 15000-20000

Payment Terms : T/T, Western Union, L/C, MoneyGram

Supply Ability : 50 sets per month

Delivery Time : 10-20 working days

Packaging Details : Container, Nude Packs, in Bulk; Export Packing Standard

Condition : New

Capacity(t/h) : 120-300TPH

Power(Kw) : 15KW

Max feeding580mm size : 580mm

Weight : 5.5t

Power type : Electric drive

Warranty : 12 months from production time or 18 months from leave factory

Application : mining,Coal,Quarry, cement factory.

After-sales service provided : Engineers available to service machinery overseas,through Video technical support

Color : Iron Grey,Yellow,white, or according to your wishes, OEM

Product name : Large capacity Electromagnetic Vibrating Feeder,High efficiency tiny electromagnetic vibrating feeder

Voltage : 220V/380V/415V/440V

Installation : Engineer's Guide, or Video guide from our engineer

Keyword : Vibrating Grizzly Feeder,Electromagnetic vibrating feeder

Contact Now

580mm Vibrating Hopper Feeder Machine ZSW1149 Model Large Capacity, Vibrating Screen Feeder

Product Description

　　ZSW Series Vibrating Feeder is mainly used to feed material into the primary crusher homogeneously and continuously. Meanwhile, it can screen the fine material and make the crusher more powerful.

ZSW Series Vibrating Feeder

Input Size:0mm--1000mm

Capacity:96-1200THP

Type:Necessary Auxiliary Equipment

Processed Materials:Limestone, Granite, Gabbro, Basalt, River Stone, Coal Gangue, Quartz, Diabase,Iron Ore, Copper Ore, Zinc Ore, Manganese Ore, etc. (for Hard Stone).

Applications:Aggregates Shaping, Mechanism sand, Bituminous Concrete,Metal Mine, Chemical, Road, Railway,Metallurgy, Construction, Highway, Water Conservancy

580mm Vibrating Hopper Feeder Machine ZSW1149 Model Large Capacity, Vibrating Screen Feeder

580mm Vibrating Hopper Feeder Machine ZSW1149 Model Large Capacity, Vibrating Screen Feeder

Working Principle

The sand making mining vibrating grizzly feeder is mainly used to feed material into primary crusher evenly and continuously. Meanwhile, it can screen material and strengthen the capacity of the crusher.It adopts double eccentric shaft vibration exciter structural characteristics to ensure that equipment can withstand the impact of falling bulk materials and increase feeding capacity.In the production process it can be massive and granular to sent materials from storage silos in uniform, regular and continuously way to the affected device,thus preventing the affected device due to uneven feed produced crash phenomenon,which extended equipment life.

ZSW Series vibrator grizzly feeder is mainly used to feed material into primary crusher evenly and continuously. Meanwhile, it can screen material and strengthen the capacity of the crusher. It adopts double eccentric shaft vibration exciter structural characteristics to ensure that equipment can withstand the impact of falling bulk materials and increase feeding capacity. In the production process it can be massive and granular to sent materials from storage silos in uniform, regular and continuously way to the affected device, thus preventing the affected device due to uneven feed produced crash phenomenon, which extended equipment life.

580mm Vibrating Hopper Feeder Machine ZSW1149 Model Large Capacity, Vibrating Screen Feeder

Features

1.Smooth vibration
2.Special bar to prevent the block of raw material
3.The distance between bars is adjustable
4.Stepless speed-regulated motor which could be additionally mounted so as to control the feeding capacity without frequent start-up of motor.
5.Stable performance &Reliable operation.
6.Easy to adjust &Easy to maintain
7.Long span life &No pollution with closed body
8.Good performance-conditioning, it can be used in any severe environments.

580mm Vibrating Hopper Feeder Machine ZSW1149 Model Large Capacity, Vibrating Screen Feeder

Specification

Model Max Feed Size(mm) Capacity (t/h) Motor Power (L*W*H) (kw) Overall Dimensions (mm) Weight (kg) Size of Funnel(mm)
ZSW380*96 500 96-160 11 3882*2224* 2121 4082 3800*960
ZSW420*110 550 120-280 15 4260*2400* 2150 5204 4900*1100
ZSW490*110 580 120-300 15 4957*2400* 2150 5320 4900*1100
ZSW590*110 600 200-350 22 6000*2500* 2150 6130 5900*1100
ZSW600*130 750 400-560 22 6082*2580* 2083 7800 6000*1300
ZSW600*150 1000 450-800 30 6627*2350* 3068 12110 6000*1500
ZSW600*200 1000 800-1200 37 6436*3853* 3014 18650 6000*2000

580mm Vibrating Hopper Feeder Machine ZSW1149 Model Large Capacity, Vibrating Screen Feeder

Questions & Answers
1. How long is the delivery time of your product?
The delivery time is within 20 working days.

2. What is the payment term?
The payment term is T/T.

3.How long is the product warranty period?
Our warranty period is 1 year, excluding wearing parts.

4.What's the after sale service of your company?
We will provide foundation drawing to the clients for installation. Besides, we can provide guidance service for installation and operation of workers, etc.

5. Can your company provide wearing parts?
We can deliver you the spare parts within 10 working days after your order. If your equipment are not manufactured by our company, please provide us the wearing parts drawing or number.
